Products > Sensor Connector > 7/8" > Mini Change 7/8" Male Panel Mount Receptacle Rear Fastened Unshielded PCB Through Hole Straight 4 Pin
product image

78006-04-PG13.5

Mini Change 7/8" Male Panel Mount Receptacle Rear Fastened Unshielded PCB Through Hole Straight 4 Pin

Color:

Silver

Number of Positions:

345
Get a Quote
Products >
  • Overview
  • Technical data
  • Certification
  • Download

Product excerpt

  1. 7/8" male panel mount receptacle, 4-pin, unshielded
  2. Front fastened for easy and secure installation
  3. PCB solder straight design ensures reliable connections
  4. Suitable for panel mounting in industrial and automation systems
  5. Built for dependable performance in demanding environments
GeneralMaterialMechanicalEnvironmentalElectrical
General
Connector TypeReceptacle
OrientationStraight
Contact TypeMale Pin
Number of Positions4
ColorSilver
Contact TerminationThrough Hole
Material
Shell MaterialCopper Alloy
Shell FinishZinc Plated
Contact FinishGold
Contact MaterialCopper Alloy
Mechanical
Wire Gauge or Range6~8mm
Fastening TypeThreaded
Mounting TypePanel Mount
Mounting FeatureBulkhead - Rear Fastened
Environmental
Ingress ProtectionIP67
Operating Temperature-25°C ~ + 80°C
Electrical
ShieldingUnshielded
Rated Current9A
Rated Voltage300V

Certification

Drawing for Mini Change 7/8″ Male Panel Mount Receptacle Rear Fastened Unshielded PCB Through Hole Straight Download

Catelog

RENHOTEC M-Series Connector Catalog [EN][CN] Download
