Mini Change 7/8" Male Panel Mount Receptacle Rear Fastened Unshielded PCB Through Hole Straight 3 Pin - Renhotec

Sensor Connector > 7/8" > Mini Change 7/8" Male Panel Mount Receptacle Rear Fastened Unshielded PCB Through Hole Straight 3 Pin

78006-03-PG13.5

Mini Change 7/8" Male Panel Mount Receptacle Rear Fastened Unshielded PCB Through Hole Straight 3 Pin

Color:

Silver

Number of Positions:

3 4 5

Get a Quote

Overview
Technical data
Certification
Download

Product excerpt

7/8" male panel mount receptacle, 3-pin, unshielded
Front fastened for easy installation
PCB solder straight design for stable connections
Ideal for panel mounting in industrial equipment and automation systems
Reliable performance for various industrial applications

GeneralMaterialMechanicalEnvironmentalElectrical

General
Connector Type	Receptacle
Orientation	Straight
Contact Type	Male Pin
Number of Positions	3
Color	Silver
Contact Termination	Through Hole

Material
Shell Material	Copper Alloy
Shell Finish	Zinc Plated
Contact Finish	Gold
Contact Material	Copper Alloy

Mechanical
Wire Gauge or Range	6~8mm
Fastening Type	Threaded
Mounting Type	Panel Mount
Mounting Feature	Bulkhead - Rear Fastened

Environmental
Ingress Protection	IP67
Operating Temperature	-25°C ~ + 80°C

Electrical
Shielding	Unshielded
Rated Current	13A
Rated Voltage	300V

Certification

Drawing for Mini Change 7/8″ Male Panel Mount Receptacle Rear Fastened Unshielded PCB Through Hole Straight
