product image

RHT-634-1296-06

M8 6 Pin Male Straight Panel Mount Receptacle, A Code Rear Fastened, Solder Cup M8

Number of Positions:

34568

please fll in your details and requirements below,and our team will get in touch with you as soon as possible.

    Get a Quote
    Products >
    • Overview
    • Technical data
    • Certification
    • Download

    Product certification

    ×

    Product excerpt

    1. 6 Pins (A-Coded): Provides secure and precise connections for multiple signals or power.
    2. A-Coded: Ensures correct orientation and compatibility.
    3. Rear Fastened: Attaches securely to the panel from the rear.
    4. Straight Orientation: Allows for direct and straightforward PCB mounting.
    5. Solder Cup Contacts: Ensures robust and reliable connections through soldering.
    EnvironmentalElectricalMaterialGeneralMechanicalShell
    Environmental
    Ingress ProtectionIP67
    Electrical
    Rated Current3A
    Material
    Shell MaterialCopper Alloy
    General
    Connector TypeReceptacle
    Mechanical
    Fastening TypeThreaded
    Shell
    Shell SizeM8
