RHT-634-1296-04

M8 Male Panel Mount Receptacle 4 Pin A Code Rear Fastened Straight Solder Cup M8

Color:

Silver

Number of Positions:

34568
Get a Quote
Products >
  • Overview
  • Technical data
  • Certification
  • Download

Product certification

×

Product excerpt

  • 4 Pins (A-Coded): Provides precise alignment for multiple signal or power connections.
  • A-Coded: Ensures correct orientation and compatibility.
  • Rear Fastened: Allows secure attachment to the panel from the rear.
  • Straight Orientation: Facilitates direct mounting on PCB (Printed Circuit Board).
  • Solder Cup Contacts: Ensures durable and reliable connections through soldering.
GeneralMaterialMechanicalEnvironmentalShellElectrical
General
Connector TypeReceptacle
OrientationStraight
Contact TypeMale Pin
Number of Positions4
KeyA
Contact TerminationSolder
Material
Shell MaterialCopper Alloy
Shell FinishZinc Plated
Contact FinishGold
Contact MaterialCopper Alloy
Mechanical
Fastening TypeThreaded
Mounting TypePanel Mount
Mounting FeatureBulkhead
Environmental
Ingress ProtectionIP67
Operating Temperature-25°C ~ + 85°C
Shell
Shell SizeM8
Electrical
ShieldingUnshielded
Rated Current3A
Rated Voltage60V

Certification

M8 M12 M16 Connector AGC07686211202-002 REACH Download
Drawing for M8 Male Panel Mount Receptacle Rear Fastened Straight Solder Cup Download

Catelog

RENHOTEC M-Series Connector Catalog [EN][CN] Download
