product image

RHT-634-3118-05

M8 5 Pin Male Right Angle Field Assembly Plug, B Code Unshielded, Solder Cup

Number of Positions:

34568

please fll in your details and requirements below,and our team will get in touch with you as soon as possible.

    Get a Quote
    Products >
    • Overview
    • Technical data
    • Certification
    • Download

    Product certification

    ×

    Product excerpt

    1. Compact Right-Angle Design: Ideal for installations in tight or constrained spaces.
    2. 5-Pin Configuration: Supports more complex signal or power connections.
    3. B Code: Used for specific signal or sensor applications with B Code configuration.
    4. Unshielded: Suitable for environments with minimal electromagnetic interference.
    5. Screw Termination: Provides a secure and stable connection with screw-secured fittings.
    6. Field-Wireable: Allows for flexible on-site wiring and adjustments.
    EnvironmentalElectricalMaterialGeneralMechanicalShell
    Environmental
    Ingress ProtectionIP67
    Electrical
    Rated Current3A
    Material
    Shell MaterialPA66+GF
    General
    Connector TypePlug
    Mechanical
    Fastening TypeThreaded
    Shell
    Shell SizeM8

    Certification

    Renhotec REACH Test Report Download

    Catelog

    RENHOTEC M-Series Connector Catalog [EN][CN] Download
    Drawing for M8 Male Field Wireable Plug Unshielded Right Angle Screw Download
