Products > Circular Connector > M8 Female Panel Mount Receptacle 8 Pin A Code Front Fastened Straight PCB Open Hole M10
- Overview
- Technical data
- Certification
- Download
Product certification
Product excerpt
- Reliable connection: M8 standard and 8-pin A-code ensure stable signal transmission.
- Flexible design: Open hole layout, compatible with a wide range of printed circuit boards.
- Durable construction: High shock and corrosion resistance, suitable for harsh environments.
- Wide range of applications: Suitable for industrial automation, sensors and control systems.
- Supports customization.
GeneralShellMechanicalMaterialEnvironmentalElectrical
| General | |
|---|---|
| Connector Type | Receptacle |
| Orientation | Straight |
| Contact Type | Female Pin |
| Number of Positions | 8 |
| Key | A |
| Contact Termination | Through Hole |
| Shell | |
|---|---|
| Shell Size | M8 |
| Mechanical | |
|---|---|
| Fastening Type | Threaded |
| Mounting Type | Panel Mount |
| Mounting Feature | Bulkhead |
| Material | |
|---|---|
| Shell Material | Copper Alloy |
| Shell Finish | Zinc Plated |
| Contact Finish | Gold |
| Contact Material | Copper Alloy |
| Environmental | |
|---|---|
| Ingress Protection | IP67 |
| Operating Temperature | -25°C ~ + 85°C |
| Electrical | |
|---|---|
| Shielding | Unshielded |
| Rated Current | 1.5A |
| Rated Voltage | 30V |
Certification
| M8 M12 M16 Connector AGC07686211202-002 REACH | Download |
