Products > Circular Connector > M8 Female Panel Mount Receptacle 3 Pin A Code Front Fastened Straight Solder Cup M12
![](https://staging.renhotec.com/wp-content/uploads/2024/03/RHT-634-1421-03_66077ea4165a4.jpg)
![](https://staging.renhotec.com/wp-content/uploads/2024/03/RHT-634-1421-03_66077ea4165a4.jpg)
- Overview
- Technical data
- Certification
- Download
Product certification
Product excerpt
High-quality M8 Female Panel Mount Receptacle with 3 pins, A Code Front Fastened design, and Solder Cup terminals. Compatible with M12 connectors. Ideal for industrial applications.
GeneralShellMechanicalMaterialEnvironmentalElectrical
General | |
---|---|
Connector Type | Receptacle |
Orientation | Straight |
Contact Type | Female Pin |
Number of Positions | 3 |
Key | A |
Contact Termination | Solder Cup |
Shell | |
---|---|
Shell Size | M8 |
Mechanical | |
---|---|
Fastening Type | Threaded |
Mounting Type | Panel Mount |
Mounting Feature | Bulkhead |
Material | |
---|---|
Shell Material | Copper Alloy |
Shell Finish | Zinc Plated |
Contact Finish | Gold |
Contact Material | Copper Alloy |
Environmental | |
---|---|
Ingress Protection | IP67 |
Operating Temperature | -25°C ~ + 85°C |
Electrical | |
---|---|
Shielding | Unshielded |
Rated Current | 3A |
Rated Voltage | 60V |
Certification
M8 M12 M16 Connector AGC07686211202-002 REACH | Download |
