Products > Energy Storage Connector > 6.0mm Power Entry Connector 60A Cable Plug Right Angled 10mm² Unshielded Cable Orange Punch Processing Terminals
product image

RHT-P006-C10-OG-T

6.0mm Power Entry Connector 60A Cable Plug Right Angled 10mm² Unshielded Cable Orange Punch Processing Terminals
Get a Quote
Products >
  • Overview
  • Technical data
  • Certification
  • Download

Product certification

×

Product excerpt

  1. 6.0mm right-angled energy storage connector, rated for 60A
  2. Designed for 10mm² unshielded cable
  3. Orange housing, ideal for energy storage applications
  4. Punch-processed terminals ensure secure and efficient connections
  5. Suitable for high-power energy storage and industrial uses
GeneralMaterialMechanicalEnvironmentalElectrical
General
Connector TypePlug
OrientationRight Angle
Number of Positions1
Contact Size6mm
Contact TerminationCrimp
Terminal Processing TypePunch Processing
ColorOrange
Material
Shell MaterialNylon
Contact MaterialT2
Contact FinishSilver
Mechanical
Mounting TypeCable Type
Wire Gauge or Range10mm²
Environmental
Ingress ProtectionIP54
Operating Temperature-40°C ~ + 125°C
Electrical
Rated Voltage1000V
Rated Current60A
ShieldingUnshielded

Certification

Renhotec Energy Storage Connector CE Certificate [EN] Download
Drawing for 6.0mm Power Entry Connector Cable Plug Right Angled Unshielded Cable Punch Processing Terminals Download

Catelog

RENHOTEC Battery Storage Connector Catalog [EN] Download
RENHOTEC EV Product Catalog [EN] Download
