product image

RHT-P006-C10-BK-T

6.0mm Power Entry Connector 60A Cable Plug Right Angled 10mm² Unshielded Cable Black Punch Processing Terminals
Get a Quote
Products >
  • Overview
  • Technical data
  • Certification
  • Download

Product certification

×

Product excerpt

  1. 6.0mm right-angled power entry connector, rated for 60A
  2. Compatible with 10mm² unshielded cable
  3. Black housing designed for energy storage and industrial use
  4. Punch-processed terminals for secure and efficient connections
  5. Ideal for high-power energy storage systems and applications
GeneralMaterialMechanicalEnvironmentalElectrical
General
Connector TypePlug
OrientationRight Angle
Number of Positions1
Contact Size6mm
Contact TerminationCrimp
Terminal Processing TypePunch Processing
ColorBlack
Material
Shell MaterialNylon
Contact MaterialT2
Contact FinishSilver
Mechanical
Mounting TypeCable Type
Wire Gauge or Range10mm²
Environmental
Ingress ProtectionIP54
Operating Temperature-40°C ~ + 125°C
Electrical
Rated Voltage1000V
Rated Current60A
ShieldingUnshielded

Certification

Renhotec Energy Storage Connector CE Certificate [EN] Download
Drawing for 6.0mm Power Entry Connector Cable Plug Right Angled Unshielded Cable Punch Processing Terminals Download
