Mini Change 7/8" Male Panel Mount Receptacle Front Fastened Unshielded Solder 3 Pin - Renhotec

Circular Connector > Mini Change 7/8" Male Panel Mount Receptacle Front Fastened Unshielded Solder 3 Pin

78009-3P

Mini Change 7/8" Male Panel Mount Receptacle Front Fastened Unshielded Solder 3 Pin

Color:

Silver

Number of Positions:

3 4 5

Get a Quote

Overview
Technical data
Certification
Download

Product excerpt

7/8" 3-pin male panel mount receptacle, front fastened
Unshielded design suitable for general industrial use
Solder terminals for reliable and durable connections
Front fastened for easy and quick panel installation
Ideal for industrial automation and power distribution systems

GeneralMaterialMechanicalEnvironmentalElectrical

General
Connector Type	Receptacle
Orientation	Straight
Contact Type	Male Pin
Number of Positions	3
Color	Silver
Contact Termination	Solder

Material
Shell Material	Copper Alloy
Shell Finish	Zinc Plated
Contact Finish	Gold
Contact Material	Copper Alloy

Mechanical
Wire Gauge or Range	6~8mm
Fastening Type	Threaded
Mounting Type	Panel Mount
Mounting Feature	Bulkhead - Front Fastened

Environmental
Ingress Protection	IP67
Operating Temperature	-25°C ~ + 80°C

Electrical
Shielding	Unshielded
Rated Current	13A
Rated Voltage	300V

Certification

Drawing for Mini Change 7/8″ Male Panel Mount Receptacle Front Fastened Unshielded Solder
