product image

RHT-634-1307-03

M8 3 Pin Male Straight Panel Mount Receptacle, A Code Front Fastened, PCB M8

Number of Positions:

34568

please fll in your details and requirements below,and our team will get in touch with you as soon as possible.



    Get a Quote
    Products >
    • Overview
    • Technical data
    • Certification
    • Download

    Product certification

    ×

    Product excerpt

    1. 3 Pins (A-Coded): Ensures precise alignment for secure connections.
    2. A-Coded: Guarantees correct orientation and compatibility.
    3. Front Fastened: Allows for secure attachment from the front side of the panel.
    4. Straight Orientation: Facilitates direct mounting on PCB (Printed Circuit Board).
    5. Panel Mount Design: Ensures stability and durability in various applications.
    EnvironmentalElectricalMaterialGeneralMechanicalShell
    Environmental
    Ingress ProtectionIP67
    Electrical
    Rated Current3A
    Material
    Shell MaterialCopper Alloy
    General
    Connector TypeReceptacle
    Mechanical
    Fastening TypeThreaded
    Shell
    Shell SizeM8

    Certification

    M8 M12 M16 Connector AGC07686211202-002 REACH Download

    Catelog

    RENHOTEC M-Series Connector Catalog [EN][CN] Download
    Drawing for M8 Male Panel Mount Receptacle Front Fastened Straight PCB Download
