product image

RHT-634-3127-04

M8 Female Field Wireable Plug 4 Pin A Code Shielded Straight Solder Cup

Color:

Silver

Number of Positions:

34568
Get a Quote
Products >
  • Overview
  • Technical data
  • Certification
  • Download

Product certification

×

Product excerpt

  1. 4 Pins (A-Coded): Provides secure connections and precise alignment for signal or power transmission.
  2. Shielded Design: Offers protection against electromagnetic interference (EMI) for reliable performance.
  3. Field Wireable: Enables easy on-site assembly and customization of cable lengths.
  4. Solder Cup Contacts: Simplifies wiring with a secure and stable soldering method.
  5. Straight Orientation: Facilitates straightforward cable routing in tight or compact spaces.
GeneralMaterialMechanicalEnvironmentalShellElectrical
General
Connector TypePlug
OrientationStraight
Contact TypeFemale Pin
Number of Positions4
KeyA
Contact TerminationSolder Cup
Material
Shell MaterialCopper Alloy
Shell FinishZinc Plated
Contact FinishGold
Contact MaterialCopper Alloy
Mechanical
Fastening TypeThreaded
Mounting TypeCable Type
Environmental
Ingress ProtectionIP67
Operating Temperature-25°C ~ + 85°C
Shell
Shell SizeM8
Electrical
ShieldingShielded
Rated Current3A
Rated Voltage60V
