Products > Energy Storage Connector > 8.0mm Power Entry Connector 120A Cable Plug Right angled 25mm² Orange Lath Machining Terminals
product image

RHT-P008-C25-OG-C

8.0mm Power Entry Connector 120A Cable Plug Right angled 25mm² Orange Lath Machining Terminals
Get a Quote
Products >
  • Overview
  • Technical data
  • Certification
  • Download

Product certification

×

Product excerpt

  1. 8.0mm energy storage connector, rated for 120A current
  2. Right-angled design for space-efficient installations
  3. Compatible with 25mm² cable for robust power transfer
  4. Orange housing with lath machining terminals for enhanced durability
  5. Ideal for energy storage and high-current applications
GeneralMaterialMechanicalEnvironmentalElectrical
General
Connector TypePlug
OrientationRight Angle
Number of Positions1
Contact Size8mm
Contact TerminationCrimp
Terminal Processing TypeLathe Processing
ColorOrange
Material
Shell MaterialNylon
Contact MaterialT2
Contact FinishSilver
Mechanical
Mounting TypeCable Type
Wire Gauge or Range25mm²
Environmental
Ingress ProtectionIP54
Operating Temperature-40°C ~ + 125°C
Electrical
Rated Voltage1000V
Rated Current120A
ShieldingUnshielded

Certification

Renhotec Energy Storage Connector CE Certificate [EN] Download
Drawing for 8.0mm Power Entry Connector Cable Plug Right angled Lath Machining Terminals Download
