Products > Energy Storage Connector > 6.0mm Power Entry Connector 120A Receptacle Busbar Teminal(M6 screw) Black
RHT-S006-T01-BK
6.0mm Power Entry Connector 120A Receptacle Busbar Teminal(M6 screw) Black- Overview
- Technical data
- Certification
- Download
Product excerpt
This high-quality Power Entry Connector features a 6.0mm size, 120A capacity, and M6 screw terminal for secure connections. The black color adds a sleek touch to your setup. Ideal for a reliable power connection in various applications.
GeneralElectricalMechanicalMaterialEnvironmental
| General | |
|---|---|
| Connector Type | Receptacle |
| Orientation | Straight |
| Number of Positions | 1 |
| Contact Size | 6mm |
| Contact Termination | Busbar |
| Color | Black |
| Electrical | |
|---|---|
| Rated Voltage | 1000V |
| Rated Current | 120A |
| Shielding | Unshielded |
| Mechanical | |
|---|---|
| Mounting Type | Panel Mount |
| Mounting Feature | Flange |
| Material | |
|---|---|
| Shell Material | Nylon |
| Contact Material | T2 |
| Contact Finish | Silver |
| Environmental | |
|---|---|
| Ingress Protection | IP54 |
| Operating Temperature | -40°C ~ + 125°C |
