Products > Energy Storage Connector > 6.0mm Power Entry Connector 60A Cable Plug Right Angled 10mm² Unshielded Cable Orange
RHT-P006-C10-OG
6.0mm Power Entry Connector 60A Cable Plug Right Angled 10mm² Unshielded Cable Orange- Overview
- Technical data
- Certification
- Download
Product excerpt
High-quality 6.0mm power entry connector featuring a 60A cable plug, right-angled design, and designed for 10mm² unshielded cables in a vibrant orange color. Ensure secure power connections with this durable and reliable connector.
GeneralElectricalMechanicalMaterialEnvironmental
| General | |
|---|---|
| Connector Type | Plug |
| Orientation | Right Angle |
| Number of Positions | 1 |
| Contact Size | 6mm |
| Contact Termination | Crimp |
| Color | Orange |
| Electrical | |
|---|---|
| Rated Voltage | 1000V |
| Rated Current | 60A |
| Shielding | Unshielded |
| Mechanical | |
|---|---|
| Mounting Type | Cable Type |
| Wire Gauge or Range | 10mm² |
| Material | |
|---|---|
| Shell Material | Nylon |
| Contact Material | T2 |
| Contact Finish | Silver |
| Environmental | |
|---|---|
| Ingress Protection | IP54 |
| Operating Temperature | -40°C ~ + 125°C |
