Products > Energy Storage Connector > Waterproof Battery Storage Connector Straight 200A Black 50mm² Unshielded Cable W Key
![](https://staging.renhotec.com/wp-content/uploads/2024/03/FSP600180CW-50U0B2RH_6605351a30fc0.jpg)
![](https://staging.renhotec.com/wp-content/uploads/2024/03/FSP600180CW-50U0B2RH_6605351a30fc0.jpg)
FSP600180CW-50U0B2RH
Waterproof Battery Storage Connector Straight 200A Black 50mm² Unshielded Cable W Key- Overview
- Technical data
- Certification
- Download
Product excerpt
Keep your batteries safe and connected with this waterproof straight connector designed for 200A capacity. The black 50mm² unshielded cable ensures reliable power transmission, while the included key adds an extra layer of security.
GeneralElectricalMechanicalMaterialEnvironmental
General | |
---|---|
Connector Type | Plug |
Orientation | Straight |
Number of Positions | 1 |
Contact Size | 8mm |
Contact Termination | Crimp |
Key | W |
Color | Black |
Electrical | |
---|---|
Rated Voltage | 1000V |
Rated Current | 200A |
Shielding | Unshielded |
Mechanical | |
---|---|
Mounting Type | Cable Type |
Wire Gauge or Range | 50mm² |
Material | |
---|---|
Shell Material | Nylon |
Contact Material | T2 |
Contact Finish | Silver |
Environmental | |
---|---|
Ingress Protection | IP67 |
Operating Temperature | -40°C ~ + 125°C |
Flammability | UL94 V-0 |
