Product excerpt
This M23 male panel mounting socket features 12 positions, A code, unshielded design, straight solder cup, and 4 holes flange. Ideal for secure and reliable connections in various applications.
GeneralShellMechanicalMaterialEnvironmentalElectrical
| General | |
|---|---|
| Connector Type | Receptacle |
| Orientation | Straight |
| Contact Type | Male Pin |
| Number of Positions | 12 |
| Key | A |
| Contact Termination | Solder Cup |
| Shell | |
|---|---|
| Shell Size | M23 |
| Mechanical | |
|---|---|
| Fastening Type | Threaded |
| Mounting Type | Panel Mount |
| Mounting Feature | Flange |
| Material | |
|---|---|
| Shell Material | Copper Alloy |
| Shell Finish | Zinc Plated |
| Contact Finish | Gold |
| Contact Material | Copper Alloy |
| Environmental | |
|---|---|
| Ingress Protection | IP67 |
| Operating Temperature | -25°C ~ + 85°C |
| Electrical | |
|---|---|
| Shielding | Unshielded |
| Rated Current | 8A |
| Rated Voltage | 260V |
