Products > Circular Connector > M23 Female Panel Mounting Socket 12 Pos A Code Unshielded Right Angle Crimp
![](https://staging.renhotec.com/wp-content/uploads/2024/03/M623D1-12-F-E_6607cb7fdc8a4.jpg)
![](https://staging.renhotec.com/wp-content/uploads/2024/03/M623D1-12-F-E_6607cb7fdc8a4.jpg)
- Overview
- Technical data
- Certification
- Download
Product excerpt
High-quality M23 Female Panel Mounting Socket with 12 positions, A Code, unshielded, and right-angle crimp design. Perfect for secure and reliable connections in industrial applications.
GeneralShellMechanicalMaterialEnvironmentalElectrical
General | |
---|---|
Connector Type | Receptacle |
Orientation | Right Angle |
Contact Type | Female Pin |
Number of Positions | 12 |
Key | A |
Contact Termination | Crimp |
Shell | |
---|---|
Shell Size | M23 |
Mechanical | |
---|---|
Fastening Type | Threaded |
Mounting Type | Panel Mount |
Mounting Feature | Flange |
Material | |
---|---|
Shell Material | Copper Alloy |
Shell Finish | Zinc Plated |
Contact Finish | Gold |
Contact Material | Copper Alloy |
Environmental | |
---|---|
Ingress Protection | IP67 |
Operating Temperature | -25°C ~ + 85°C |
Electrical | |
---|---|
Shielding | Unshielded |
Rated Current | 8A |
Rated Voltage | 260V |
