R02-M02-10022-20

MCX Male to F Female Bulkhead RF Cable Assembly with 50Ohm RG174 Coax
Get a Quote
Products >
  • Overview
  • Technical data
  • Certification
  • Download

Product excerpt

High-quality MCX male to F female bulkhead RF cable assembly with 50-ohm RG174 coax, ideal for reliable RF signal transmission. SKU: R02-M02-10022-20.
GeneralMechanicalEnvironmentalElectrical
General
Conversion Style
1st Connector SeriesMCX Plug
1st Contact TypeMale Pin
1st Connector OrientationStraight
2nd Connector SeriesF Jack
2nd Contact TypeFemale Pin
2nd Connector OrientationStraight
FeaturesHex
Mechanical
Suitable CableRG174
Environmental
Operating Temperature-40°C ~ + 85°C
Electrical
Impedance50 Ohms
Frequency Range0-4Ghz
