product image

RHT-634-3065-17

M12-17P A Coded Female Receptacle Rear Fastened Solder M16
Get a Quote
Products >
  • Overview
  • Technical data
  • Certification
  • Download

Product certification

×

Product excerpt

This M12-17P A coded female receptacle featuring rear fastened solder termination is a reliable solution for your electronic connections. Explore this high-quality M16 connector for secure and efficient connectivity.
GeneralShellMechanicalMaterialEnvironmentalElectrical
General
Connector TypeReceptacle
OrientationStraight
Contact TypeFemale Pin
Number of Positions17
Contact TerminationSolder Cup
KeyA
Shell
Shell SizeM12
Mechanical
Fastening TypeThreaded
Mounting TypePanel Mount
Mounting FeatureBulkhead - Front Fastened
Material
Shell MaterialCopper Alloy
Shell FinishNickel Plated
Contact FinishGold
Contact MaterialBrass
Environmental
Ingress ProtectionIP67
Operating Temperature-40°C ~ + 85°C
Electrical
ShieldingUnshielded
Rated Current1.5A
Rated Voltage30V
