Products > Circular Connector > M8 Female Field Wireable Plug 4 Pin A Code Unshielded Straight Solder
![](/wp-content/themes/flatsome-child/assets/imgs/no_image_2.png)
![](/wp-content/themes/flatsome-child/assets/imgs/no_image_2.png)
- Overview
- Technical data
- Certification
- Download
Product certification
Product excerpt
This M8 female field wireable plug is equipped with 4 pins supporting A code connection. It is unshielded and designed for straight soldering, ensuring secure electrical connections.
GeneralShellMechanicalMaterialEnvironmentalElectrical
General | |
---|---|
Connector Type | Plug |
Orientation | Straight |
Contact Type | Female Pin |
Number of Positions | 4 |
Key | A |
Contact Termination | Solder |
Shell | |
---|---|
Shell Size | M8 |
Mechanical | |
---|---|
Fastening Type | Threaded |
Mounting Type | Cable Type |
Material | |
---|---|
Shell Material | PA66+GF |
Contact Finish | Gold |
Contact Material | Copper Alloy |
Environmental | |
---|---|
Ingress Protection | IP67 |
Operating Temperature | -25°C ~ + 85°C |
Electrical | |
---|---|
Shielding | Unshielded |
Rated Current | 3A |
Rated Voltage | 30V |
Certification
M8 M12 M16 Connector AGC07686211202-002 REACH | Download |
