MS3112E8-3P/PT02E-8-3P
MIL-DTL-26482 Connector MS3112E8-3P Male Box Mount Receptacle 3 Pin- Overview
- Technical data
- Certification
- Download
Product excerpt
High-quality MIL-DTL-26482 connector featuring MS3112E8-3P male box mount receptacle with 3 pins. Ideal for secure and reliable connections.
GeneralShellMechanicalMaterialElectricalEnvironmental
General | |
---|---|
Connector Type | Receptacle |
Orientation | Straight |
Contact Type | Male Pin |
Number of Positions | 3 |
Contact Arrangements | 8-3 |
Contact Termination | Solder Cup |
Color | Olive Green |
Shell | |
---|---|
Shell Size | 8 |
Mechanical | |
---|---|
Fastening Type | Bayonet |
Mounting Type | Panel Mount |
Mounting Feature | Flange |
Wire Gauge or Range | AWG24,22,20 |
Material | |
---|---|
Shell Material | Aluminum Alloy |
Contact Finish | Gold |
Insulating Material | Synthetic Rubber |
Contact Material | Copper Alloy |
Electrical | |
---|---|
Shielding | Unshielded |
Rated Current | 7.5A |
Rated Voltage | 600V |
Environmental | |
---|---|
Operating Temperature | -55°C ~ + 125°C |
