Products > Circular Connector > Mini Change 7/8" Female Panel Mount Receptacle Rear Fastened Unshielded PCB Solder Straight 4 Pin
- Overview
- Technical data
- Certification
- Download
Product excerpt
A high-quality 7/8" female panel mount receptacle for your PCB soldering needs. This unshielded connector is rear fastened and straight, ideal for various electronic applications.
GeneralMechanicalMaterialEnvironmentalElectrical
| General | |
|---|---|
| Connector Type | Receptacle |
| Orientation | Straight |
| Contact Type | Female Pin |
| Number of Positions | 4 |
| Color | Silver |
| Contact Termination | Through Hole |
| Mechanical | |
|---|---|
| Wire Gauge or Range | 6~8mm |
| Fastening Type | Threaded |
| Mounting Type | Panel Mount |
| Mounting Feature | Bulkhead - Front Fastened |
| Material | |
|---|---|
| Shell Material | Copper Alloy |
| Shell Finish | Zinc Plated |
| Contact Finish | Gold |
| Contact Material | Copper Alloy |
| Environmental | |
|---|---|
| Ingress Protection | IP67 |
| Operating Temperature | -25°C ~ + 80°C |
| Electrical | |
|---|---|
| Shielding | Unshielded |
| Rated Current | 9A |
| Rated Voltage | 300V |
