Products > HVIL Series Connector > 2 POS Metal High Power Electric vehicle Cable Plug 125A 25mm2 Shielded Cable Y Key Straight
NI1-1-S060-2YYN-C08
2 POS Metal High Power Electric vehicle Cable Plug 125A 25mm2 Shielded Cable Y Key Straight
Get a Quote
- Overview
- Technical data
- Certification
- Download
Product certification
Product excerpt
This high power electric vehicle cable plug is designed for heavy-duty applications with a 125A capacity. The shielded cable and Y key straight design ensure optimal performance and durability. Ideal for use in electric vehicles and other high-power applications.
GeneralMaterialMechanicalEnvironmentalElectrical
General | |
---|---|
Connector Type | Plug |
Orientation | Straight |
Number of Positions | 2 |
Contact Size | 6mm |
Contact Termination | Crimp |
Key | Y |
Color | Silver |
Features | Integrated Internal HVIL |
Material | |
---|---|
Shell Material | Zinc Alloy |
Contact Material | Copper Alloy |
Contact Finish | Nickel |
Mechanical | |
---|---|
Mounting Type | Cable Type |
Wire Gauge or Range | 25mm² |
Environmental | |
---|---|
Ingress Protection | IP67 |
Operating Temperature | -40°C ~ + 125°C |
Flammability | UL94 V-0 |
Electrical | |
---|---|
Rated Voltage | 800V |
Rated Current | 125A |
Shielding | Shielded |
Certification
High Voltage Interlock Connectors CE | Download |
